規格型號 |
最大高度 | 最小高度 | 工作行程 | 缸徑 | 工作阻力 |
重量 (kg) |
(mm) | (mm) | (mm) | (mm) | (KN) | ||
DW45-200/100X(Q) | 4500 | 2533 | 1967 | φ 100 | 200 | 90.5 |
DW42-200/100X(Q) | 4200 | 2373 | 1827 | φ 100 | 200 | 85.15 |
DW40-200/100X(Q) | 4000 | 2263 | 1737 | φ 100 | 200 | 80.1 |
DW38-200/100X(Q) | 3800 | 2153 | 1647 | φ 100 | 200 | 77.3 |
DW35-350/100X(Q) | 3500 | 1980 | 1520 | φ 100 | 350 | 73 |
DW31.5-350/100X(Q) | 3150 | 1800 | 1350 | φ 100 | 350 | 67 |
DW28-350/100X(Q) | 2800 | 1620 | 1180 | φ 100 | 350 | 61 |
DW25-350/100X(Q) | 2500 | 1450 | 1050 | φ 100 | 350 | 56 |
DW22-350/100X(Q) | 2240 | 1300 | 940 | φ 100 | 350 | 51.5 |
DW20-350/100X(Q) | 2000 | 1170 | 830 | φ 100 | 350 | 47 |
DW18-350/100X(Q) | 1800 | 1055 | 745 | φ 100 | 350 | 43.5 |
DW16-350/100X(Q) | 1600 | 940 | 660 | φ 100 | 350 | 40 |
DW14-350/100X(Q) | 1400 | 830 | 570 | φ 100 | 350 | 38 |
DW12-350/100X(Q) | 1200 | 720 | 480 | φ 100 | 350 | 32.5 |
DW10-350/100X(Q) | 1000 | 615 | 385 | φ 100 | 350 | 29.5 |
DW08-350/100X(Q) | 800 | 510 | 290 | φ 100 | 350 | 26 |
DW06-350/100X(Q) | 630 | 420 | 210 | φ 100 | 350 | 23 |
DW35-200/100X(Q) | 3500 | 1980 | 1520 | φ 100 | 200 | 62.6 |
DW31.5-200/100X(Q) | 3150 | 1800 | 1350 | φ 100 | 200 | 57.26 |
DW28-250/100X(Q) | 2800 | 1620 | 1180 | φ 100 | 250 | 51.97 |
DW25-250/100X(Q) | 2500 | 1450 | 1050 | φ 100 | 250 | 47.01 |
DW22-300/100X(Q) | 2240 | 1300 | 940 | φ 100 | 300 | 42.6 |
DW20-300/100X(Q) | 2000 | 1170 | 830 | φ 100 | 300 | 38.78 |
DW18-300/100X(Q) | 1800 | 1055 | 745 | φ 100 | 300 | 35.4 |
DW16-300/100X(Q) | 1600 | 940 | 660 | φ 100 | 300 | 32.04 |
DW14-300/100X(Q) | 1400 | 830 | 570 | φ 100 | 300 | 28.82 |
DW12-300/100X(Q) | 1200 | 720 | 480 | φ 100 | 300 | 25.57 |
DW10-300/100X(Q) | 1000 | 615 | 385 | φ 100 | 300 | 22.5 |
DW08-300/100X(Q) | 800 | 510 | 290 | φ 100 | 300 | 19.38 |
DW06-300/100X(Q) | 630 | 420 | 210 | φ 100 | 300 | 16.75 |
規格型號 |
最大高度 | 最小高度 | 工作行程 | 缸徑 | 工作阻力 |
重量 (kg) |
(mm) | (mm) | (mm) | (mm) | (KN) | ||
DW45-250/110X(Q) | 4500 | 2533 | 1967 | φ 110 | 250 | 95.5 |
DW42-250/110X(Q) | 4200 | 2373 | 1827 | φ 110 | 250 | 90.15 |
DW40-250/110X(Q) | 4000 | 2263 | 1737 | φ 110 | 250 | 88.1 |
DW38-250/110X(Q) | 3800 | 2153 | 1647 | φ 110 | 250 | 85.3 |
DW35-300/110X(Q) | 3500 | 1980 | 1520 | φ 110 | 300 | 80 |
DW31.5-300/110X(Q) | 3150 | 1800 | 1350 | φ 110 | 300 | 74.2 |
DW28-300/110X(Q) | 2800 | 1620 | 1180 | φ 110 | 300 | 68.5 |
DW25-350/110X(Q) | 2500 | 1450 | 1050 | φ 110 | 350 | 66.53 |
DW22-350/110X(Q) | 2240 | 1300 | 940 | φ 110 | 350 | 61.28 |
DW20-350/110X(Q) | 2000 | 1170 | 830 | φ 110 | 350 | 56.72 |
DW18-350/110X(Q) | 1800 | 1050 | 745 | φ 110 | 350 | 52.68 |
DW16-350/110X(Q) | 1600 | 940 | 660 | φ 110 | 350 | 48.66 |
DW14-350/110X(Q) | 1400 | 830 | 570 | φ 110 | 350 | 44.81 |
DW12-350/110X(Q) | 1200 | 720 | 480 | φ 110 | 350 | 40.94 |
DW10-350/110X(Q) | 1000 | 615 | 385 | φ 110 | 350 | 37.26 |
DW08-350/110X(Q) | 800 | 510 | 290 | φ 110 | 350 | 33.53 |
DW06-350/110X(Q) | 630 | 420 | 210 | φ 110 | 350 | 30.39 |
DW35-400/110X(Q) | 3500 | 1980 | 1520 | φ 110 | 400 | 86.15 |
DW31.5-400/110X(Q) | 3150 | 1800 | 1350 | φ 110 | 400 | 79.79 |
DW28-400/110X(Q) | 2800 | 1620 | 1180 | φ 110 | 400 | 72.64 |
DW25-400/110X(Q) | 2500 | 1450 | 1050 | φ 110 | 400 | 66.53 |
DW22-400/110X(Q) | 2240 | 1300 | 940 | φ 110 | 400 | 61.28 |
DW20-400/110X(Q) | 2000 | 1170 | 830 | φ 110 | 400 | 56.72 |
DW18-400/110X(Q) | 1800 | 1050 | 745 | φ 110 | 400 | 52.68 |
DW16-400/110X(Q) | 1600 | 940 | 660 | φ 110 | 400 | 48.66 |
DW14-400/110X(Q) | 1400 | 830 | 570 | φ 110 | 400 | 44.81 |
DW12-400/110X(Q) | 1200 | 720 | 480 | φ 110 | 400 | 40.94 |
DW10-400/110X(Q) | 1000 | 615 | 385 | φ 110 | 400 | 37.26 |
DW08-400/110X(Q) | 800 | 510 | 290 | φ 110 | 400 | 33.53 |
DW06-400/110X(Q) | 630 | 420 | 210 | φ 110 | 400 | 30.39 |
